40m3/h Electrocoagulation System for Wastewater Treatment 220V-480V

Ampliación de imagen : 40m3/h Electrocoagulation System for Wastewater Treatment 220V-480V

Datos del producto:

Lugar de origen:	Shanghai, China
Nombre de la marca:	ECOPRO

Pago y Envío Términos:

Cantidad de orden mínima:	1
Precio:	$36,897

Contacto

Descripción detallada del producto

Productividad:	40m3/h	Peso:	2298 kg
Tipo de procesamiento:	Filtración	Fuerza:	3 kW, 30 kW, 20 kW
Voltaje:	220 V, 380 V, 110 V	Capacidad:	40m3/h
Peso del electrodo:	11500 kilogramos	Peso vacío:	3500 kg
Operación Peso:	31000kg	Capacidad de tratamiento:	1m3/h
Consumo de energía:	3kw/h	Dimensión:	10006501500 mm
Peso del electrodo:	650 kg	Peso vacío:	400 kg
Operación Peso:	1500 kg
Resaltar:	40m3/h electrocoagulation wastewater treatment system , electrocoagulation system 220V-480V , industrial wastewater electrocoagulation unit

Electrocoagulation System in Wastewater Treatment Plant for Sewage Disposal

Electrocoagulation system is a wastewater treatment process that utilizes metal hydroxide produced by a soluble metal anode during flocculation to remove contaminants from water. The anode material typically uses aluminum, iron, and other readily available, inexpensive metals.

Specification	Value
Treating Capacity	1m³/h
Power Consumption	3kw/h
Dimension	1000×650×1500mm
Electrode Weight	650kg
Empty Weight	400kg
Operation Weight	1500kg

Electrocoagulation System Principle

Electrochemical reaction: Fe→Fe²⁺+2e

Anodizing reaction: 2OH⁻→2[O]+2e→O₂+2e. The nascent oxygen [O] has strong oxidation function comparable to UV, H₂O₂ and O₃.

Cathode reduction: 2H⁺+2e→2[H]→H₂. Nascent hydrogen can break bonds, COD, chromophore functional groups and multi-chain health.

The above oxidation and reduction functions occur continuously on the plates.

Electrocoagulation System Features

Wide adaptability of power supply: 220V-480VAC range available
Safe and convenient: Embedded isolated voltage circuit ensures electrical safety with multiple abnormal indications and protection (phase loss, overload, overcurrent, overvoltage, zero voltage, etc.)
Automatic control: Automatically detects ion state in water to adjust current and voltage
Energy efficient: Fe(OH)₂ and Fe(OH)₃ serve as excellent coagulants, eliminating the need for polymer additives

Company Introduction

Shanghai Ecopro Environmental Engineering Co., Ltd., established in 2017, specializes in one-stop water & wastewater treatment equipment and separation service environment solutions. As a professional environmental engineering company, we provide industry-leading equipment, services, and systematic solutions including static screens, rotary drum screens, polymer dosing systems, DAF systems, electrochemistry systems, screw presses, plate filter presses, sludge dryers, Mutag Biochips, sodium hypochlorite generators, and various pumps.

Persona de Contacto: Shirley

Teléfono: 86-17320131993

Fax: 86-21-58900516
