Continuous Operation DAF System for Industrial Wastewater Treatment with Effective Grease Removal

Name: Continuous Operation DAF System for Industrial Wastewater Treatment with Effective Grease Removal
Brand: Shanghai Ecopro Environmental Engineering Co., Ltd.
Price: 13608 USD
Availability: InStock

Ampliación de imagen : Continuous Operation DAF System for Industrial Wastewater Treatment with Effective Grease Removal

Datos del producto:

Pago y Envío Términos:

Cantidad de orden mínima:	1
Precio:	13608

Contacto

Descripción detallada del producto

Modelo no.:	DAF	Capacidad:	5m3/h
Potencia del compresor de aire:	0.55kw	Potencia de la bomba disuelta:	3kw
Potencia del deslizador:	0.1kw	Poder del agitador de la coagulación:	0.55kw
Potencia del agitador de floculación:	0.55kw	Potencia del agitador de pH:	0.55kw
Dimensiones:	Se trata de un sistema de medición de las emisiones de gases de escape.	Capacidad de producción:	100000/WEEK
Microburbujas:	generando	Captura del subsuelo:	Sí
Eslagado automático:	Nivel de líquido controlado	Liberación sin obstrucción:	Alta eficiencia
pH preferido:	6 ~ 9
Resaltar:	Continuous Operation DAF System , Industrial Usage Wastewater Treatment System , Effective Grease Removal Dissolved Air Flotation

Dissolved Air Flotation (DAF) System for Wastewater Treatment

The Dissolved Air Flotation Device operates continuously to effectively remove grease and suspended particles from wastewater.

DAF System Introduction

Dissolved Air Flotation is a water treatment process that clarifies wastewaters by removing suspended matter such as oil or solids. The process involves dissolving air in the water under pressure and then releasing it at atmospheric pressure in a flotation tank basin.

The released air forms microbubbles that adhere to suspended matter, causing it to float to the surface where it can be removed by a skimming device.

DAF System Work Processdiv>

1. Wastewater enters RT1 (coagulation reaction tank) and RT2 (flocculation reaction tank) from the equalization tank through the lift pump.

2. The wastewater coagulates with PAC and flocculates with PAM to form flocs.

3. The wastewater and dissolved water enter the reaction zone of the DAF tank where microbubbles and flocs mix and adhere.

4. The resulting solid particles (with density less than water) float to the surface and are scraped to the slag tank.

5. Clean water is collected and discharged (or sent to next process), with a portion recirculated to form dissolved water.

DAF System Featuresdiv>

Microbubbles generating system
Subsurface capture technology
Automatic slagging controlled by liquid level
Non-clogging releasing with high efficiency

Applications of DAF Systemdiv>

Municipal Sewage
Slaughter House wastewater
Metallurgical Industry Wastewater
Spraying Sewage
Printing & Dyeing Sewage
Metal-Processing Sewage
Mining Stone Wastewater
Electronic Sewage

How to Select the Right Modeldiv>

Consider these factors when selecting a DAF system:

Wastewater type (dairy, car washing, slaughter house, food processing, etc.)
SS content (ppm or mg/L)
Oil & Grease & Fat (FOG) content (ppm or mg/L)
PH level (6-9 preferred)
BOD and COD levels (ppm or mg/L)

Fabrication Processdiv> Continuous Operation DAF System for Industrial Wastewater Treatment with Effective Grease Removal 2

Technical Datadiv> Continuous Operation DAF System for Industrial Wastewater Treatment with Effective Grease Removal 3

Packagingdiv> Continuous Operation DAF System for Industrial Wastewater Treatment with Effective Grease Removal 4
